Wireless 3 in 1 Ultrasound Scanner SMARTSONO-3.3 Triple Headed
$5,500.00 $3,429.00
Frequency : Convex probe: 3.5/5.0mhz. Linear probe: 7.5/10mhz. Cardiac probe: 2.5/5.0mhz.
Depth : Convex probe: 90-305mm. Linear probe: 20-80mm. Cardiac probe: 90-160mm.
Host : IOS Android and windows.
Connection : 802.11.n WIFI(AP).
Playback frames : 100, 200, 500, 1000 optional.
Display mode : B, B/M, color, PW, PDI.
Description
Wireless 3 in 1 Ultrasound Scanner SIFULTRAS-3.3
Triple Headed:
Convex, Linear and Cardiac Probe
The 3 in 1 wireless ultrasound SMARTSONO-3.3 include convex, linear and cardiac scan modes in same one probe. In addition, the SMARTSONO-3.3 supports 5G, works on iOS, Android and Windows. There is no need to change probe head. As this can be done by simply changing the software. SMARTHEALTHUP’s engineer team developed this portable ultrasound machine in a way for it to be easy and convenient to use.
The wireless ultrasound scanner SMARTSONO-3.3 is a highly versatile device. It serves various medical practitioners and fields. First of all, the convex probe. Aside from being used as a point of care (POC) ultrasound in internal and external medicine. This probe is also mainly used for OB/GYN, liver, kidneys, Urinary … etc.
On the other hand, the Linear transducer of the SMARTSONO-3.3 provides qualitative and quantitative data. Thanks to it’s smaller footprint it aids in evaluation of soft tissues, joints, nerves and muscles. Further, the linear ultrasound scanner is also a highly effective POC ultrasound scanner. In the evaluations of; MSK (Muscular-skeletal), Vascular , nevers…ect. , Ultrasound-guided.
Furthermore, the linear probe is dependable guide for many procedures. To name a few; anesthesia, injection, Puncture, BNB, PICC, midline, Dry needling, …Hence this device can serve many medical fields, from Orthopedics, Pediatrics, Sports medicine, … to emergency/ critical care.
Last but not least, the cardiac probe. This probe does not only gratify cardiologist of its effectiveness, but also emergency doctors, anesthetists… etc. Thanks to its lower frequency (3.5-5 MHz) the probe allows the practitioner to make PW measurements. To accurately and precisely diagnose not only the blood flow velocity but also echocardiograms in general ( for eg: FOCUS, transthoracic echo TTE ..)
Color Doppler Mode is needed to:
- Give a visual overview of flow within the vessel or heart.
- Rapid identification of vessels, valves, turbulent flow.
- Evaluate flow direction and velocity.
- Measure volume and percent vascularity when combined with 3D Mode.
- Guidance for reproducible quantification of flow velocities using Pulsed-Wave Doppler.
- Locate area of stenosis or thrombosis.
- Determine the existence and amount of arterial plaques and associated turbulent flow.
- Find small vessels such as mouse coronary arteries, femoral and arcuate arteries.
- Evaluate blood flow after a stroke or other cases due to impaired blood flow.
- Observe blood flow to major organs such as heart, kidney, liver pancreas, carotid, abdominal aorta, and others.
Features:
- This types machine is 3 in 1 probe.
- Include the convex probe , linear probe and cardiac probe.
- Moreover, no need change the probe head. only change from the software.
- Changing the probe will have not harm the machine .
- Furthermore, it is easy and convenient to use.
- Cardiac probe: Cardiac.
- Linear : MSK(Muscular-skeletal), Orthopedics, Vascular, Pediatrics, Sports medicine, anesthesia , injection , Puncture , nevers…ect. Point of care, Ultrasound-guided procedures, Veterinary and among other medical fields.
- Convex: OB&GYN, liver ,kidney ,Urinary …etc .Point of care, Internal medicine,
Specifications:
- Probe: Wireless ultrasound scanner SMARTSONO-3.3 . Convex probe, Linear probe, Cardiac probe.
- Frequency:
Convex probe: 3.5/5.0mhz.
Linear probe: 7.5/10mhz.
Cardiac probe: 2.5/5.0mhz.
- Depth:
Convex probe: 90-305mm.
Linear probe: 20-80mm.
Cardiac probe: 90-160mm.
- Host: IOS Android and windows.
- Connection: 802.11.n WIFI(AP).
- Playback frames: 100, 200, 500, 1000 optional.
- Throughout: 150Mbit/s.
- Field of view: 80 degree.
- Display mode: B, B/M, color, PW, PDI.
- Image gray scale: 256 level.
- Channel: 64.
- Frame: 24s/f.
- Gain: 40-110Db.
- Language: English.
- Power: by built-in battery.
- Power consumption: 4W (probe run) /1.5W (probe stop).
- Replaceable Battery: Yes.
- Battery last: 3 hours(working time), More than 5 hours(stand by time).
- Machine Radius: 44mm.
- Machine Size: 157(h)x70(w)x30(d) mm.
- Package Size: 240(h)x235(w)x100(d) mm.
- Weight: 227gram.
